Mean Well LRS-50-5 | 5VDC 10A Enclosed Power Supply

$ 25.18

+ Free Shipping To USA
Specifications Output Voltage 5 VDC Current 10 A Power 50 W Adj Voltage Range 4.5 ∼ 5.5 VDC LED Indicator Yes Input Voltage 85 ∼ 264 VAC / 120 ∼ 373 VDC Current 0.56 A @ 230 VAC Inrush Current 45 A Efficiency 83% Connections Input Screw terminals Output Screw terminals Protections Over Voltage 5.9 ∼ 7.3 VDC | Re-power to recover Overload 110 ∼ 150% rated output | Recovers once fault removed Environment Working Temp. Tcase= -30 ~ 70°C (refer datasheet for derating) Cooling Method Convection Working Humidity 20 ~ 90% RH non-condensing IP Rating IP20 Dimensions L x W x H 99 x 82 x 30 mm Weight 0.230 kg Carton Quantity 60 pieces / 14.8 kg Other MTBF 645K HRS MIN Warranty 3 Years Approvals RCM (Australia)
Get a Quote
