Mean Well HDR-30-12 | 12VDC 2A DIN Rail Power Supply

Specifications Output Voltage 12 VDC Current 2.0 A Power 30 W Adj Voltage Range 10.8 ∼ 13.8 VDC Input Voltage 85 ∼ 264 VAC / 120 ∼ 370 VDC Current 0.48 A @ 230 VAC Inrush Current 45 A @ 230 VAC Efficiency 88% Connections Input Screw terminals Output Screw terminals Protections Over Voltage 15 ~ 18 VDC | Re-power to recover Overload 105 ~ 160% rated output | Recovers once fault removed Environment Working Temp. Tcase= -30 ~ 70°C (refer datasheet for derating) Working Humidity 20 ~ 90% RH non-condensing IP Rating IP20 Dimensions L x W x H 35 x 90 x 54.5 mm Weight 0.120 kg Carton Quantity 96 pieces / 12.5 kg Other DIN Rail TS35/7.5 or TS35/15 MTBF 968.1K HRS MIN Warranty 3 Years Approvals RCM (Australia)
