Mean Well MDR-60-24 | 24VDC 2.5A DIN Rail Power Supply

Specifications Output Voltage 24 VDC Current 2.5 A Power 60 W Adj Voltage Range 24 ∼ 30 VDC Input Voltage 85 ∼ 264 VAC / 120 ∼ 370 VDC Current 1.0 A @ 230 VAC Inrush Current 60 A @ 230 VAC Efficiency 88% Connections Input Screw terminals Output Screw terminals Protections Over Voltage 31.2 ∼ 36.0 VDC | Re-power to recover Overload 105 ~ 150% rated output | Recovers once fault removed Environment Working Temp. Tcase= -20 ~ 70°C (refer datasheet for derating) Working Humidity 20 ~ 90% RH non-condensing IP Rating IP20 Dimensions L x W x H 40 x 90 x 100 mm Weight 0.330 kg Carton Quantity 42 pieces / 14.8 kg Other DIN Rail TS35/7.5 or TS35/15 MTBF 299.2K HRS MIN Warranty 3 Years Approvals RCM (Australia)
