Mean Well HDR-100-24N | 24VDC 3.83A DIN Rail Power Supply

Specifications Output Voltage 24 VDC Current 3.83 A Power 100 W Adj Voltage Range 21.6 ∼ 29 VDC Input Voltage 85 ∼ 264 VAC / 120 ∼ 370 VDC Current 1.6 A @ 230 VAC Inrush Current 70 A @ 230 VAC Efficiency 90% Connections Input Screw terminals Output Screw terminals Protections Over Voltage 30 ∼ 36 VDC | Re-power to recover Overload 105 ~ 150% rated output | Recovers once fault removed Environment Working Temp. Tcase= -30 ~ 70°C (refer datasheet for derating) Working Humidity 20 ~ 90% RH non-condensing IP Rating IP20 Dimensions L x W x H 70 x 90 x 54.5 mm Weight 0.270 kg Carton Quantity 48 pieces / 14 kg Other DIN Rail TS35/7.5 or TS35/15 MTBF 856.5K HRS MIN Warranty 3 Years Approvals RCM (Australia)
